Products Description
| Family | P/N | Configuration | VRWM (V) | VBR (V) | Cj （pF) | IPP@8/20us (A) | Vc@Max IPP | PPP (W) | Package |
| 3.3V | JS33U1GD20-2 | 1-Line Uni-Directional | 3.3V | 4.80 | 150.00 | 27 | 11.00 | 300 | DFN1006-2 |
| JE33U1RD20-2 | 1-Line Uni-directional | 3.3 | 4.20 | 0.60 | 6 | 14.00 | 100 | DFN1006-2 | |
| JE33B1LD20-2 | 1-Line Bi-Directional | 3.3 | 3.50 | 56.00 | 30 | 10.00 | 300 | DFN1006-2 | |
| JE33B1RD20-2 | 1-Line Bi-Directional | 3.3 | 5.00 | 0.30 | 4 | 25.00 | 100 | DFN1006-2 | |
| JE33U1GD20-2 | 1-Line Uni-Directional | 3.3 | 4.80 | 150.00 | 27 | 11.00 | 300 | DFN1006-2 | |
| JE33U1LD20-2 | 1-Line Uni-Directional | 3.3 | 3.50 | 60.00 | 10 | 10.00 | 100 | DFN1006-2 | |
| JE33B1UD20-2L | 1-Line Bi-Directional | 3.3 | 4.30 | 3.00 | 2.5 | 10.00 | 25 | DFN1006-2 | |
| JE33B1UD20-2 | 1-Line Bi-Directional | 3.3 | 4.30 | 25.00 | 8 | 10.00 | 80 | DFN1006-2 | |
| 4.5V | JS45B1LD20-2 | 1-Line Bi-Directional | 4.5 | 5 | 150.0 | 30.0 | 14.50 | 430 | DFN1006-2 |
| JS45B1GD20-2 | 1-Line Bi-Directional | 4.5 | 4.8 | 100.0 | 40.0 | 10.00 | 400 | DFN1006-2 | |
| JS45B1GD20-2L | 1-Line Bi-Directional | 4.5 | 5.0 | 150.0 | 20.0 | 12.50 | 250 | DFN1006-2 | |
| JS45B1GD21-2 | 1-Line Bi-Directional | 4.5 | 4.8 | 100.0 | 60.0 | 9.00 | 600 | DFN1006-2 | |
| 4.8V | JS48U1GD20-2 | 1-Line Uni-Directional | 4.8 | 5-6.5 | 200.0 | 80.0 | 8.80 | 700 | DFN1006-2 |
| 5V | JS05U1GD20-2A | 1-Line Uni-Directional | 5.0 | 6.0 | 230.0 | 40.0 | 12.00 | 480 | DFN1006-2 |
| JS05U1GD20-2 | 1-Line Uni-Directional | 5.0 | 6.0 | 180.0 | 22.0 | 12.00 | 250 | DFN1006-2 | |
| JS05B1GD20-2H | 1-Line Bi-Directional | 5.0 | 5.5 | 300.0 | 100.0 | 10.50 | 900 | DFN1006-2 | |
| JS05U1GD20-2H | 1-Line Bi-Directional | 5.0 | 5.8 | 110.0 | 50.0 | 9.00 | 500 | DFN1006-2 | |
| JE05B1LD20-2 | 1-Line Bi-Directional | 5.0 | 6.00 | 60.00 | 25.0 | 12.00 | 300 | DFN1006-2 | |
| JE05B1UD20-2M | 1-Line Bi-Directional | 5.0 | 5.50 | 13.00 | 8.0 | 12.00 | 150 | DFN1006-2 | |
| JE05B1RD20-2H | 1-Line Bi-directional | 5.0 | 6.00 | 0.30 | 9.0 | 32.00 | 280 | DFN1006-2 | |
| JE05U1LD20-2A | 1-Line Uni-Directional | 5.0 | 6.00 | 100.00 | 15.0 | 14.00 | 200 | DFN1006-2 | |
| JS05B1LD21-2 | 1-Line Bi-directional | 5.0 | 6.00 | 50.00 | 15.0 | 14.00 | 200 | DFN1006-2 | |
| JE05B1MD20-2 | 1-Line Bi-Directional | 5.0 | / | 0.05 | / | 40.00 | / | DFN1006-2 | |
| JE05U1RD20-2 | 1-Line Uni-Directional | 5.0 | 6.00 | 1.00 | 5.0 | 16.00 | 80 | DFN1006-2 | |
| JE05B1RD20-2 | 1-Line Bi-Directional | 5.0 | 6.50 | 0.50 | 4.0 | 25.00 | 100 | DFN1006-2 | |
| JE05U1RD21-2L | 1-Line Uni-Directional | 5.0 | 6.00 | 0.75 | 8.0 | 18.00 | 160 | DFN1006-2 | |
| JE05B1LD21-2 | 1-Line Bi-Directional | 5.0 | 6.00 | 50.00 | 15.0 | 14.00 | 200 | DFN1006-2 | |
| JE05B1UD20-2 | 1-Line Bi-Directional | 5.0 | 6.00 | 20.00 | 8.0 | 13.00 | 100 | DFN1006-2 | |
| JE05B1UD20-2L | 1-Line Bi-Directional | 5.0 | 6.00 | 5.50 | 3.0 | 12.00 | 40 | DFN1006-2 | |
| JE05U1LD20-2 | 1-Line Uni-Directional | 5.0 | 6.00 | 60.00 | 8.0 | 12.00 | 100 | DFN1006-2 | |
| JE05U1GD20-2 | 1-Line Uni-Directional | 5.0 | 6.00 | 160.00 | 22.0 | 14.00 | 300 | DFN1006-2 | |
| JE05B1UD21-2 | 1-Line Bi-Directional | 5.0 | 6.00 | 3.00 | 2.0 | 10.00 | 18 | DFN1006-2 | |
| JE05B1RD22-2 | 1-Line Bi-Directional | 5.0 | 6.00 | 0.80 | 14.0 | 15.00 | 210 | DFN1006-2 | |
| JE05B1RD20-2LU | 1-Line Bi-Directional | 5.0 | 8.00 | 0.50 | 5.0 | 6.00 | 35 | DFN1006-2 | |
| 7V | JE07B1UD20-2 | 1-Line Bi-Directional | 7.0 | 8.00 | 15.00 | 5.0 | 14.00 | 70 | DFN1006-2 |
| JE07U1GD20-2 | 1-Line Uni-Directional | 7.0 | 8.00 | 130.00 | 17.0 | 18.00 | 300 | DFN1006-2 | |
| 12V | JE12B1RD20-2 | 1-Line Bi-Directional | 12.0 | 13.3 | 0.3 | 2.5 | 32.00 | 80 | DFN1006-2 |
| JE12B1LD20-2A | 1-Line Bi-Directional | 12.0 | 13.30 | 35.00 | 15.0 | 25.00 | 375 | DFN1006-2 | |
| JE12B1MD20-2 | 1-Line Bi-Directional | 12.0 | / | 0.05 | / | 40.00 | / | DFN1006-2 | |
| JE12U1LD20-2 | 1-Line Uni-Directional | 12.0 | 13.30 | 65.00 | 14.0 | 25.00 | 350 | DFN1006-2 | |
| JE12U1LD20-2M | 1-Line Uni-Directional | 12.0 | 13.30 | 60.00 | 9.0 | 25.00 | 200 | DFN1006-2 | |
| JE12B1UD20-2 | 1-Line Bi-Directional | 12.0 | 13.30 | 11.00 | 6.0 | 26.00 | 150 | DFN1006-2 | |
| JE12B1UD20-2C | 1-Line Bi-Directional | 12.0 | 13.30 | 4.50 | 4.0 | 24.00 | 88 | DFN1006-2 | |
| JE12B1UD20-2L | 1-Line Bi-Directional | 12.0 | 13.30 | 9.50 | 4.0 | 24.00 | 88 | DFN1006-2 | |
| JE12B1LD20-2 | 1-Line Bi-Directional | 12.0 | 13.00 | 30.00 | 8.0 | 22.50 | 180 | DFN1006-2 | |
| 15V | JE15B1RD20-2 | 1-Line Bi-Directional | 15.0 | 16.0 | 0.6 | 14.0 | 22.00 | 308 | DFN1006-2 |
| JE15U1LD20-2 | 1-Line Uni-Directional | 15.0 | 16.50 | 50.00 | 10.0 | 32.00 | 320 | DFN1006-2 | |
| 18V | JE18B1UD20-2 | 1-Line Bi-Directional | 18.0 | 20.00 | 20.00 | 7.0 | 42.00 | 300 | DFN1006-2 |
| JE18B1RD20-2 | 1-Line Bi-Directional | 18.0 | 19.50 | 0.30 | 2.0 | 40.00 | 80 | DFN1006-2 | |
| 24V | JE24B1RD20-2 | 1-Line Bi-Directional | 24.0 | 25.00 | 0.50 | 1.0 | 40.00 | 40 | DFN1006-2 |
| JE24B1UD20-2 | 1-Line Bi-Directional | 24.0 | 27.00 | 20.00 | 5.0 | 40.00 | 300 | DFN1006-2 | |
| JE24U1LD20-2 | 1-Line Uni-Directional | 24.0 | 27.00 | 40.00 | 5.0 | 44.00 | 220 | DFN1006-2 | |
| JE24B1MD20-2 | 1-Line Bi-Directional | 24.0 | / | 0.05 | / | 40.00 | / | DFN1006-2 | |
| JE24U1LD21-2 | 1-Line Uni-Directional | 24.0 | 26.70 | 54.00 | 10.0 | 42.00 | 420 | DFN1006-2 | |
| 36V | JE36U1LD20-2 | 1-Line Uni-Directional | 36.0 | 38.00 | 30.00 | 4.0 | 75.00 | 300 | DFN1006-2 |
| JE36B1UD20-2A | 1-Line Bi-Directional | 36.0 | 38.00 | 40.00 | 7.0 | 61.0 | 400 | DFN1006-2 | |
| JE36B1UD20-2L | 1-Line Bi-Directional | 36.0 | 38.00 | 15.00 | 4.0 | 65.0 | 250 | DFN1006-2 |
