| Family | P | VDSS (V) | ID (A) | Package | VGS (V) | Vth (V) | Package Level Data |
| JL2301 | P | -20 | -1.5 | SOT-23 | ±10 | -0.5 | -0.7 | -1.0 | - | - | 99 | 120 | 138 | 165 |
| JL3415 | P | -20 | -4.9 | SOT-23 | ±10 | -0.5 | -0.7 | -0.9 | - | - | 30 | 37 | 36 | 47 |
| JLM3401T1-3 | P | -30 | -4.4 | SOT-23 | ±12 | -0.6 | -0.9 | -1.4 | 45 | 55 | 53 | 68 | 64 | 96 |
| JL3401 | P | -30 | -4.2 | SOT-23 | ±12 | -0.7 | -0.9 | -1.3 | 43 | 60 | 80 | 85 | 110 | 135 |
| JL3407 | P | -30 | -4.1 | SOT-23 | ±20 | -1 | -1.4 | -3 | 50 | 60 | - | - | - | - |
| JLMS84T1-3 | P | -50 | -0.13 | SOT-23 | ±20 | -0.9 | -1.4 | -2.0 | 1700 | 5000 | 1900 | 6000 | - | - |
| JLMP1002AT1-3 | P | -100 | -2 | SOT-23 | ±20 | -1 | -1.8 | -2.5 | 280 | 350 | 300 | 400 | - | - |
| JLMP126AT1-3 | P | -12 | -6 | SOT-23 | ±10 | -0.4 | -0.65 | -1 | - | - | 19 | 28 | 27 | 40 |
| JLMP202AT1-3 | P | -20 | -2 | SOT-23 | ±10 | -0.4 | -0.7 | -1 | - | - | 90 | 120 | 140 | 180 |
| JLMP304P5AT1-3 | P | -30 | -4.5 | SOT-23 | ±12 | -0.6 | -0.9 | -1.3 | 36 | 50 | 40 | 60 | 52 | 68 |
| JLMP2034AT1-3 | P | -20 | -3.4 | SOT-23 | ±10 | -0.4 | -0.7 | -1 | - | - | 50 | 75 | 60 | 90 |
