产品详情
| Family | N | VDSS (V) | ID (A) | Package | VGS (V) | Vth (V) | Package Level Data | |||||||
| JL3134KL | N | 20 | 0.88 | SOT23-6L | ±12 | 0.35 | 0.75 | 1.1 | - | - | 220 | 300 | 290 | 400 |
| JLM8205T2-6 | N | 20 | 6 | SOT23-6L | ±8 | 0.5 | 0.7 | 0.9 | - | - | 21 | 25 | 26 | 35 |
| JLMN205N5AT1-6 | N | 20 | 5.5 | SOT23-6L | ±12 | 0.5 | 0.65 | 0.9 | - | - | 18 | 23 | 22 | 35 |
