Products Description
| Family | P/N | Configuration | VRWM (V) | VBR (V) | Cj （pF) | IPP@8/20us (A) | Vc@Max IPP | PPP (W) | Package |
| High Power TVS | SMAJ | 1-Line Bi-Directional/Uni-Directional | 3.3-440 | 4.1-492 | / | / | 7.3-713 | / | DO-214AC |
| SMBJ | 1-Line Bi-Directional/Uni-Directional | 5-440 | 6.4-492.0 | / | / | 9.2-713.0 | / | DO-214AA | |
| SMCJ | 1-Line Bi-Directional/Uni-Directional | 5-440 | / | / | 2.1-163 | 9.2-713.0 | 1500 | DO-214AB | |
| SMDJ | 1-Line Bi-Directional/Uni-Directional | 5-220 | 6.4-244 | / | 8.4-326.1 | / | 3000 | DO-214AB | |
| 5.0SMDJ | 1-Line Bi-Directional/Uni-Directional | 12-170.0 | 13.3-189 | / | 18.2-252 | 19.9-275 | 5000 | DO-214AB |
